Get Primary, Secondary, Tertiary DNS values and more from Multiple Servers

Came across a unique request to get primary, secondary, and tertiary DNS values for multiple computers/servers across the domain. I started writing the script and got what I wanted.

Now this started off as just to query for DNS Server information, but then I thought to add other pieces to get myself a good Network Inventory of all the servers in the environment.

I am utilizing the Win32_NetworkAdapterConfiguration WMI Class to get the required information.

You can modify the script below to suit your needs. The complete list of settings that can be captured:

Since the scripts are querying for information it is best if it runs from a DC or a privileged server with an account that has privileged access.

To get the results you need the following two scripts:

Get-NetworkInfo.ps1:

I needed to get all the network information for all the domain controllers in the domain. So the following code retrieves it for me. This came really handy in viewing all the DNS settings setup on all the DCs and correcting them if needed.

Get-Remote-NetworkInfo.ps1

This will get the information and export to an excel file that you can have handy for reference or auditing. Hope this helps!

Get All DCs in the Entire Forest

Getting a know a new environment for a new client and I a quickly needed information about all domain controllers in the entire forest.

Wrote a small little script to provide me all the information I needed:



Convert a Dynamic IP to Static

Working on a project where on some servers the DHCP assigned addresses needs to be converted to static. Since there is always more than one…I needed to script it.

Here is a quick way to do it via PowerShell.

Hope this helps!

NSLookup still showing IP of demoted Domain Controller

So had an interesting issue today where a Domain Controller (DC) was demoted yet the IP of the demoted DC was still showing up when running nslookup internaldomain.local

Demoted DC: MWDC04 / IP: 10.14.111.111

I had done the metadata cleanup and tried many suggestions when googling the subject. To my surprise none of the solutions I found worked.

I had removed the IP address from the Primary DNS Server and saw entries for:

(same as parent folder) Host(A)  10.14.111.111
(same as parent folder) NameServer (NS)  10.14.111.111

I also looked under internaldomain.local > _msdcs and deleted entries from there.

After clearing the cache and waiting for replication, did a nslookup again and the IP was still there.

Well, there are some good and bad things about Microsoft DNS.

The BAD:

You cannot search DNS values in DNS Management. You are limited to searching just the names.

THE GOOD:

All DNS entries are stored in a flat file on the DNS Server “C:\WINDOWS\system32\dns\internaldomain.local.dns” (The default location). JACKPOT!

I opened it up in Notepad++, did a search for IP and DNS name of the demoted server(MWDC04-10.14.111.111) and started deleting matched entries. I was so surprised to find entries that were deeply buried under “domaindnszones” & “forestdnszones” and a few other subzones.

Cleared the cache again and waited for replication. Once replication completed I tried nslookup internaldomain.local and this time it didn’t list the demoted DC anymore.

I hope this saves others time, because finding a record in DNS might be like searching for a needle in a haystack!

Speed up Active Directory & DNS replication between Sites

Using the standard GUI Microsoft Management Consoles to make the change to speed up Active Directory replication is not possible. The best result of using administrator consoles will be to increase domain replication between domain controllers to 15 minutes. These large time values were instituted into Active Directory at version 1 because inter-site connections during that era of computing and networking were much lower in bandwidth with the most common being frame-relay or 56k circuits. Since then, inter-site connections and the Internet speeds have increased tremendously so faster domain controller replication is possible even over wan links.

Fast Intersite Replication Interval – Speed up DC Replication, Updates are in Seconds

To enabled faster Intersite Replication, to nearly the speed of intra-site or LAN replication, use ADSI Edit.
Start ADSI edit and go to
Configuration > then Sites > Inter Site Transports > IP.
Note this setting cannot be enabled for SMTP InterSite links.
Unless it has been renamed, right click on  the default Intersite link and choose properties. Then scroll down to the options line. Double-click and change the value to 1 if it has a value .
 <not set> is the default unless this option has been previously modified.  Once changed to 1, click OK twice to save and close the properties window.
Force a replication using Sites and Services so this setting get pushed/pulled to the other domain controllers.
Test by creating a couple of test accounts in AD.
Check your other domain controller or controllers for the new account. You will see it appear in seconds.

Resolve IP Addresses from List of Host Names

If you have a list of hostnames/servers that you need IP addresses for its cumbersome to ping each server and get the ip address.

PowerShell to the rescue!

To do this we need a file called Server.txt with each server’s hostname on each line. I am storing the file in D:\Data\Servers.txt.

Once we run the script below it resolves the ip via DNS and stores to another file called D:\Data\Addresses.txt.

All the IP addresses are getting pulled from their DNS value.

Creating Security Groups for File Shares in Bulk using PowerShell

Security Groups are great for managing large groups for permissions.  A client requested that they needed to have Read-Only, Read-Write, and Ready-Modify (allow for deleting) for all their file shares for better management.

Getting the Share Names

In order for me to create the groups I needed the share names. PowerShell to the rescue!

Type the following on the File Server/ Cluster to list all the shares and capture the output in a text file:

On your file-server you may have a lot of share but for example purposes I am showing just one.

Output should be similar to:

Cleaning up the Share Names

Now that we have the Share names we need to do a bit of cleanup to avoid having duplicates.

  • We need to remove all entries for hidden shares “$”
  • We need to remove duplicates
  • We need to change the case of the share names to lower case. ( I prefer lowercase but you can decide to do what best fits your needs)

Follow my guide to removing duplicates in a text file using NotePad++

Once the sharenames are clean save it to a text file.

Client Requirement for the Security Groups:

For each file share there are three security groups needed:

  • <Sharename>_RO : Read-Only
  • <Sharename>_RW : Read & Write
  • <Sharename>_RM : Read & Modify

For PowerShell to do this I needed to create a .CSV file with all the security group entries.  Now, there are many ways this can be done. I will share what I have been doing.

Open up Microsoft Excel and copy the share on a column to the right (lets say K2)

Now on Cell A2 your value should be =CONCATENATE(K2,"_RW") and drag it down.

It should look something like this:

Do the same for RO & RM. Now you have all the security groups names you need to create.

Create a file called  FileShares_Groups.csv  using the following format.

Create the file Create Security Groups for File Shares.ps1

Copy the two files: FileShares_Groups.csv & Create Security Groups for File Shares.ps1  into a folder called C:\scripts  on the Domain Controller.

Run the PowerShell script and see the security groups get created.





Remove duplicates, blank lines, spaces, to get unique values and sort data in one operation

From time to time I come across this need; where I need to scrub a file where there are duplicates, there are blank lines, the sort order is all wack, and it just needs to be formatted to where it can be more readable and/or usable.

This method just doesn’t apply to text, but also applies to numbers.

Software Prerequisites:

  • NotePad++
  • TextFX Characters Plug-in for NotePad++

Enabling TextFX Characters Plug-in

Install NotePad++ with all defaults

Goto Plugins > Plugin Manager > Show Plugin Manager

Install TextFX Characters Plugin

Once successfully downloaded it will prompt for a restart.

After a successful restart of the application you should now see the TextFX entry in the toolbar.

Removing duplicates, blank lines, and sorting data

  • Paste the text into Notepad++ (CTRL+V). As you can see, there were lines and half of them were blank.

  • Mark all the text (CTRL+A). Click TextFX → Click TextFX Tools → Check +Sort outputs only UNIQUE (at column) lines (if not already checked).

  • Click TextFX → Click TextFX Tools → Click Sort lines case insensitive (at column)

  • Duplicates and blank lines have been removed and the data has been sorted alphabetically. (The first line that may appear empty contains a space, which is regarded as a character and is included in the list of unique data.)

Changing to lowercase

To change the text to lowercase Goto: TextFX > TextFX Characters > lower case

This has saved me a lot of time when working with IP addresses or cleaning up text.



How to setup network after RHEL/CentOS 7 minimal installation

After installing RHEL/CentOS 7 minimal, You may not able to connect network in that machine. This will happen because Ethernet interfaces are not enabled by default.
This guide explain you to setup network on RHEL/CentOS 7.

Setup network on CentOS 7 minimal

First, type “nmcli d” command in your terminal for quick list ethernet card installed on your machine:

CentOS_7-network-setup

“nmcli d” command output

Type “nmtui” command in your terminal to open Network manager. After opening Network manager chose “Edit connection” and press Enter (Use TAB button for choosing options).

CentOS_7-Network-manager-screen

CentOS_7 Network manager screen

Now choose you network interfaces and click “Edit

Edit-your-network-interfaces



Edit your network interfaces

DHCP configuration

Choose “Automatic” in IPv4 CONFIGURATION and check Automatically connect check box and press OK and quit from Network manager.

Set-ip-adress-using-DHCP

Set ip adress using DHCP

Reset network services:

Now your server will get IP Address from DHCP .

CentOS-7-check-ip-address

CentOS 7 check ip address.
