NSLookup still showing IP of demoted Domain Controller

So had an interesting issue today where a Domain Controller (DC) was demoted yet the IP of the demoted DC was still showing up when running nslookup internaldomain.local

Demoted DC: MWDC04 / IP: 10.14.111.111

I had done the metadata cleanup and tried many suggestions when googling the subject. To my surprise none of the solutions I found worked.

I had removed the IP address from the Primary DNS Server and saw entries for:

(same as parent folder) Host(A)  10.14.111.111
(same as parent folder) NameServer (NS)  10.14.111.111

I also looked under internaldomain.local > _msdcs and deleted entries from there.

After clearing the cache and waiting for replication, did a nslookup again and the IP was still there.

Well, there are some good and bad things about Microsoft DNS.

The BAD:

You cannot search DNS values in DNS Management. You are limited to searching just the names.

THE GOOD:

All DNS entries are stored in a flat file on the DNS Server “C:\WINDOWS\system32\dns\internaldomain.local.dns” (The default location). JACKPOT!

I opened it up in Notepad++, did a search for IP and DNS name of the demoted server(MWDC04-10.14.111.111) and started deleting matched entries. I was so surprised to find entries that were deeply buried under “domaindnszones” & “forestdnszones” and a few other subzones.

Cleared the cache again and waited for replication. Once replication completed I tried nslookup internaldomain.local and this time it didn’t list the demoted DC anymore.

I hope this saves others time, because finding a record in DNS might be like searching for a needle in a haystack!

ConfigMgr 2012 R2 – WSUS sync fails with HTTP 503 errors

Ran into this issue with ConfigMgr 2012 R2 where it was unable to synchronize Software Update Point with the WSUS server. A review of the component status messages for the SMS_WSUS_SYNC_MANAGER component on the primary site server reveals errors related to WSUS synchronization which are similar to the following:
Message ID: 6703 WSUS Synchronization failed. Message: The request failed with HTTP status 503: Service Unavailable. Source: Microsoft.UpdateServices.Administration.AdminProxy.CreateUpdateServer.
Got the following error when trying to open Update Services on the WSUS server

Error: Connection Error An error occurred trying to connect to the WSUS server. This error can happen for a number of reasons. Please contact your network administrator if the problem persists. Click the Reset Server Node to connect to the server again.

In addition to the above, attempts to access the URL for the WSUS Administration website (i.e., http://CMCASSERVER:8530) fails with the error:

HTTP Error 503. The service is unavailable

In this situation, the most likely cause is that the WsusPool Application Pool in IIS is in a stopped state, as shown below.

Also, the Private Memory Limit (KB) for the Application Pool is probably set to the default value of 1843200 KB.

If you encounter this problem, increase the Private Memory Limit to 4GB (4000000 KB) and restart the Application Pool. To increase the Private Memory Limit, select the WsusPool Application Pool and click Advanced Settings under Edit Application Pool. Then set the Private Memory Limit to 4GB (4000000 KB).

After the Application Pool has been restarted, monitor the SMS_WSUS_SYNC_MANAGER component status, wcm.log and wsyncmgr.log for failures. Please note that it may be necessary to increase the Private Memory Limit to 8GB (8000000 KB) or higher depending on the environment.

Now WSUS is back online!

Active Directory Ports required between client and domain controllers

Active Directory uses several ports for communication between domain controllers and clients. These ports are required both by client computers and Domain Controllers. As an example, when a client computer tries to find a domain controller it always sends a DNS Query over Port 53 to find the name of the domain controller in the domain.

  • 53- DNS
  • 88- Kerberos
  • 123- Time Service
  • 135- for domain controllers-to-domain controller and client to domain controller operations.
  • 138- For File Replication Service between domain controllers.r
  • 139- For File Replication Service between domain controllers.
  • 389- For LDAP to handle normal queries from client computers to the domain controllers.
  • 445- File replication/SMB
  • 464- For change the password of user account
  • 636- secure LDAP
  • 3268- Global Catalog server
  • 3269 – Global Catalog server [Secure]
  • 5722-File replication, DFSR
  • 9389- ADDS web service
  • 53248- FRS RPC

Above mentioned ports should be opened in Firewall between client computers and domain controllers, or between domain controllers, will enable Active Directory to function properly.

Going back to the basics….moving out of Amazon Drive!

As of June 8, 2017, it was announced that when when users try to sign up for Amazon Drive they will not be able to select an unlimited cloud storage option. Instead they can choose either 100 GB for $11.99 per year, or 1 TB for $59.99, with up to 30 TB available for an additional $59.99 per TB. (The prior pricing was unlimited everything for $59.99.) My data came up to about 5TB, which according to their new pricing structure would cost me $300+ (Data is always growing!!).

That is quite costly for just 5TB of storage when I can buy two 8TB drives and have it locally in a RAID configuration or a mirrored set. I shopped around with other popular cloud providers but each and every one of them have some sort of limitations. I decided to purchase two 8TB drives and maintain it locally.

I found very little help on Google when searching for ways to move out of Amazon Drive with ease. I found a lot of cool little utilities but none were able to do a clean and consistent sync copy/move. It most cases the application would either hang, or incomplete the job.

I tried a lot of tools to get a synced local copy but the process seemed harder and harder. I tried a lot of freeware and shareware utilities as well as those offered by Amazon. I am just listing my personal experiences here so that I can save time for those whole have a similar situation.

Tools I tried:

Amazon Drive Desktop Sync

  •  Horrible transfer speeds +
  • Buggy Software
  • Startup & Resuming files would delay download significantly.

SymLink (MacOS/ Linux)

  • Somewhat works but metadata is lost.

NetDrive

  • Mounts the Amazon Cloud Drive and a Network Drive
  • Constant disconnects + too many app updates
  • Application hangs with large files
  • Service needed to be restarted multiple times to connect with Amazon

Cloudberry Explorer

  • Quirks around Admin Mode.
  • Ghostfiles (0kb) leftover.
  • Acts like an FTP Client but missing a lot features

rClone (Banned)

AllwaySync

  • The Oneway transfer feature is nice but it was taking a long time between files
  • This might have worked if my filebase was a whole lot smaller but failed for larger jobs.

Expandrive

  • Similar to NetDrive but a whole lot stable, but would fail on larger files.

Odrive

  • Horrible interface. Didn’t work most of time.

& a few more applications…. that didn’t work out!

Syncovery

Syncovery was the  winner in my case. This tools was the best in speed and got me an exact copy out from Amazon Cloud drive. It supports resuming! It is available on all platforms. It has a nice layout and can run as a scheduled job!

It took Syncovery literally 2 days to get all of my data downloaded. I was simply amazed at how efficient this tool was working. It maintained a consistent speed. Didn’t lose any metadeta. I ran a file check and all of them checked out 100%.

The trial version worked in my case and I am considering getting the Pro version. It excelled where all other failed. It wasn’t a resource hog and did the job in the first go! Thank you Syncovery!



Couple of lessons learned in getting success with all my data downloaded.

  1. Metadata is important especially when dealing with older files. Try not of lose it, as once it is lost there is no going back.
  2. Don’t copy to the same path as the original. Use an external drive and copy it there.
  3. If dealing with a lot of smaller files break them into chunks or batches to avoid application hang
  4. Apart from Syncovery, there were some utilities that might delete the files from Amazon and put them in Trash. Make sure you look there if you notice files missing file. It is most certainly there. I personally didn’t have this issue but some people have reported this with other utilities.
  5. Share your experiences to help out others.

Conclusion

I am in no way promoting a product from Syncovery, but based on my personal experience I found it to be the easiest to move the amount of data I had from Amazon down to my local server.  I am going to sway away from the public cloud space for a while at-least for my personal stuff. Based on the pricing, limitation of file size and types, and amount of data I have, I am still searching for good cloud store. I am evaluating ownCloud for now. If I ever goto a public cloud storage solution again, I am going to try my exit exercise/ strategy prior to bulk upload.

Another strategy people are recommending is hosting all the files in a VM on AWS/ Google/ Azure. My issue there is access cost. If my access is within the VM I am good, but any data I am pulling or accessing out of the VM – I am paying for it!

Get .Net Framework Version for the .DLL & .EXE files

Working with many app/dev teams it is hard to find which version of Dot Net  an application was designed or made in.

Now if your application server has multiple drives and depending on which drive the application resides it may be hard to find this information.

Let’s assume there are two drives C: and D:.

We will start with D: drive as it is easy.

Now the C: drive is a little more work. The above method wont work because C:  drive has system files and depending on your rights you may not have access to them.

You may get the following error:

But there is a way we can get this accomplished. Good old dos commands to the rescue! We are basically going to get a list of .exe and .dll files from the C: drive and then run the above code against it.

Lets capture the files:

Now we have the .EXE files stored in C_EXE_Paths.txt and we query it for .NET versions and save the output to DotNetFiles_C_EXE.txt

Similarly we have the .DLLfiles stored in C_DLL_Paths.txt and we query it for .NET versions and save the output to DotNetFiles_C_DLL.txt

You might get errors for files that do not meet criteria or fails to list .Net version.

This can be surpressed by using:

The output would be similar to:

Now you can import this in Excel and go crazy!  😉

Additionally, if you want to detect what version of .NETis installed on your server here is a cool utility (ASoft .NET Version Detector) to get you the info, as well as download links to the installer in case you need to download and install.

Provisioning a New Office 365 User and Mailbox from Exchange Hybrid via PowerShell

Working with many Office365 clients, I receive queries on how to go about provisioning users and mailboxes for an Exchange hybrid deployment.

To begin with, let’s assume a couple things.

  1. We have a Windows 2012 R2 member server with Azure AD Connect (AAD Connect) version 1.1.105.00 (or newer) and the Azure AD Module for PowerShell installed; and
  2. We have an Exchange 2013 CU11 (or newer) server configured for hybrid with an active O365 tenant.

Now that we’ve established a baseline, there are a couple of options to perform the task of provisioning an AD user, creating a mailbox, and assigning an Office 365 license.

  1. The first option would be to create an AD user, create an on premise mailbox, migrate the mailbox to Office 365, and assign a license; or
  2. The second option would be to create an AD user, create a remote (or Office 365) mailbox, and assign a license.

In this post, I will cover the second option simply because it includes fewer steps and attempts to avoid confusion around where the mailbox should be created.

Do not create an AD user and then go to the Office 365 portal to create a new user and associated mailbox. This method will not properly create a synchronized O365 user and mailbox.

STEP 1: CREATE USER & MAILBOX

From the Exchange server, first create the AD user with remote mailbox using one command via Exchange Management Shell (EMS or Exchange PowerShell)…

In the command above, I created the AD user in an OU named “Office 365 Users”, set the password to “EnterPasswordHere”, and will require the user to change their password at next logon. However, I did not assign an SMTP address or remote routing address assuming that the email address policies are configured to be applied as new mailboxes are created.

STEP 2: SYNCHRONIZE USER

Once the AD user and mailbox are created, the AD object must to be synchronized to O365 in order to add the user with associated mailbox in the tenant. With the new version of AAD Connect, the scheduled sync time occurs every 30 minutes. In my case, I’m not that patient and will manually force a sync to O365.

From the server with AAD Connect installed, via an elevated PowerShell console, run the following command to perform the sync to O365…

This task will synchronize all changes made to AD since the user and mailbox were created.

STEP 3: ASSIGN LICENSE

In the final step, I assign an O365 license to the newly created and synchronized user. The following commands can be run from any machine that has both Microsoft Online Services Sign-in Assistant for IT Professionals RTW and Windows Azure Active Directory Module for Windows PowerShell installed. In my case, they are installed on each server, as well as my admin workstation.

Connect to O365 via PowerShell from an elevated PowerShell console; or using Azure AD Module for PowerShell console.

Confirm the new user does not have an O365 license assigned.

This command returns unlicensed O365 users in which the “isLicensed” parameter is “False”.

The next command returns the “AccountSkuId“, or subscription license(s), of my tenant that I will use to assign to the new user.

The AccountSkuId will look something similar to “tenantname:ENTERPRISEPACK“; where “ENTERPRISEPACK” represents my Office 365 Enterprise E3 subscription. Other subscriptions will have different representations.

Before I can assign any licenses to my new user, the user must be assigned a location (or country code). Since I’m am located in the United States, I use “US” as the two letter country code for the user, using this command…

Now that I’ve set a location for the new user, I can assign a license from my associated O365 subscription, using this command…

Finally, the user can access their assigned mailbox in Exchange Online.

Add Alternate Email Address or Recovery Email Address for Office365 Administrator

In Office365, depending on the admin role of an account you may want to add an alternate email address for password recovery. This is a basically a self-service password reset for Administrators of Office365.

Quick way to do this is with PowerShell:

If this setting is unset for an administrator, Office365 gives you a nice reminder about adding an alternate email address in case your primary account gets locked out.

You can add this information when first setting up the account:

It can also be added for an existing admin user by going to the Gear, Office 365 settings, and edit your settings in the ‘me’ section, you can enter your mobile phone number and alternate email there.

Map a network drive using PowerShell

Make sure you are using the latest version of PowerShell. On Windows 8/10 run it as administrator and type the following:

Where:

Z – is the Drive Letter

Within ” ” is the path of the network share that will be presented as the root of the drive letter Z

The -Persist parameter so that you can not only see the name of your new drive in Windows explorer, but also know it’s still there the next time you logon.

-Name <String>
Specifies a name for the new drive. For persistent mapped network drives, type a drive letter. For temporary drives type you are not limited to drive letters.
Required? true
Position 1

-PSProvider <String>
Specifies the Windows PowerShell provider, for example, FileType or Registry.
Required? true
Position? 2

-Root <String>
Specifies the data store location, for example, \\Server\Drivers, or a registry key such as HKLM:\Software\Microsoft\Windows NT\CurrentVersion.
Required? true
Position? 3

Speed up Active Directory & DNS replication between Sites

Using the standard GUI Microsoft Management Consoles to make the change to speed up Active Directory replication is not possible. The best result of using administrator consoles will be to increase domain replication between domain controllers to 15 minutes. These large time values were instituted into Active Directory at version 1 because inter-site connections during that era of computing and networking were much lower in bandwidth with the most common being frame-relay or 56k circuits. Since then, inter-site connections and the Internet speeds have increased tremendously so faster domain controller replication is possible even over wan links.

Fast Intersite Replication Interval – Speed up DC Replication, Updates are in Seconds

To enabled faster Intersite Replication, to nearly the speed of intra-site or LAN replication, use ADSI Edit.
Start ADSI edit and go to
Configuration > then Sites > Inter Site Transports > IP.
Note this setting cannot be enabled for SMTP InterSite links.
Unless it has been renamed, right click on  the default Intersite link and choose properties. Then scroll down to the options line. Double-click and change the value to 1 if it has a value .
 <not set> is the default unless this option has been previously modified.  Once changed to 1, click OK twice to save and close the properties window.
Force a replication using Sites and Services so this setting get pushed/pulled to the other domain controllers.
Test by creating a couple of test accounts in AD.
Check your other domain controller or controllers for the new account. You will see it appear in seconds.
